Corrosion Resistant Gr2 Titanium Welded Pipe ASTM B338 for Shell Tube Heat Exchanger

Place of Origin	Baoji City, China
Brand Name	Changsheng
Certification	ISO9001:2015
Model Number	Welded Pipe Titanium in Gr2
Minimum Order Quantity	100kg
Price	USD 16.0/KG - USD 18.0/KG
Packaging Details	Soft film wrapped inside, export standard crate outside.
Delivery Time	20-25 work days
Payment Terms	L/C, T/T
Supply Ability	60 Tons per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details

Materials	Pure Titanium In Grade 2	Diameter	6mm ~ 1200mm
Wall Thickness	0.3mm ~ 25mm	Surface	Bright Surface/Acid Washing Surface
Tube Shape	Round Welded Pipe Titanium	Tube Type	Welded Shell & Tube Heatexchanger
Manufacture Standard	ASTM B338, ASME SB338, ASTM B862	Application	Heat Exchangers, Condernsers, Eveporators, Cooler
Highlight	Gr2 Titanium Welded Pipe , Corrosion Resistant Titanium Welded Pipe , ASTM B338 Titanium Welded Pipe

Leave a Message

Product Description

Welded Pipe Titanium Gr2 Shell Tube Heatexchanger ASTM B338

Titanium welded pipe is a kind of metal pipe with good corrosion resistance and high strength, which is widely used in Oil & Gas, Pulp & Paper, Chemical, Petrochemical, Water treatment, Fume treatment, Shipbuilding, Mining, Power generation, etc,.

Welded pipe in titanium Gr.2 mainly used for condensers in power plant, heat exchangers in desalination, and many other corrosion resistance fields. Titanium welded tubes as the alternative material of stainless steel welded tubes, no pollution, less maintenance, long life span, and also light weight and anti-corrosion. We supply Gr2 titanium welded tubes, Gr12 titanium welded tubes, the main advantages of our welded tubes are for their uniform wall thickness and uniform tolerance. Welded tubes and welded pipes used as condensing pipe, heat exchange pipe and fluid conveying pipe.

We manufacture welded pipes in the following materials: Titanium Gr1 Gr2 Gr12

Manufacturing Standard: ASTM B338 ASME SB338 ASTM B862

Production range: OD 6mm-1200mm. Wall thickness: 0.3mm-25.0mm. Length within:15m full length or cut-to-size)

Testing: Ultrasonic test, Eddy current inspection, Hydraulic test

Processing: welding(automatic arc-welding process or other method of welding)

Titanium Welded Tubes Regular Spes:

Diameters: φ19.05, φ25, φ32, φ38, φ57, φ76, φ89, φ108, φ114, φ133, φ141, φ159, φ168, φ219, φ273, φ325, φ355, φ377, φ406, φ426, φ480, etc,.

Features of Titanium Welded Tubing for Shell & Tube Heatexchanger:

*Usually used for heating and cooling.

*Uniform wall thickness and uniform tolerance

*Welded tubing has a competitive price advantage compared with seamess tubing.

*Pure titanium tube has super strong corrosion proof ability and high intensity.

*It has the character of strong corrosion resistance ,good heat resistance, high conductivity, non-toxic,no-scale,no-blocking, no contamination of medium,and not easy to formed oxides on the surface.

Titanium Welded Pipes Mechanical Properties:

ASTM Grade	Alloy composition	Tensile strength		Yield strength		Elongation %
ASTM Grade	Alloy composition	ksi	Mpa	ksi	Mpa	Elongation %
GR1	Unalloyed Ti(Pure)35A-CP1	35	240	25	170	24
GR2	Unalloyed Ti(Pure)50A-CP2	50	345	40	275	20
GR12	Ti-0.3Mo-0.8Ni	70	483	50	345	18

Titanium Pipe and Titanium Tube Industrial Applications

Oil and Gas Industry

Power Plant Industry
Marine Industry

Seawater desalination industry
Chemical and petrochemical industry
Pulp and paper industry

Plating and anodizing industry
Medical industry
Nuclear industry

Sports equipment(Bicycle, Wheelchair, etc,.)

Tags: Gr.2 titanium welded tube, welded titanium pipes, Condensers titanium tubing
