3.7165 Round Bar In Titanium Grade 5 CNC Machining Bar Material

  • 3.7165 Round Bar In Titanium Grade 5 CNC Machining Bar Material
  • 3.7165 Round Bar In Titanium Grade 5 CNC Machining Bar Material
  • 3.7165 Round Bar In Titanium Grade 5 CNC Machining Bar Material
  • 3.7165 Round Bar In Titanium Grade 5 CNC Machining Bar Material
  • 3.7165 Round Bar In Titanium Grade 5 CNC Machining Bar Material
Place of Origin Baoji City, China
Brand Name Changsheng Titanium
Certification ISO9001:2015
Model Number 3.7165 Round Bar In Titanium Grade 5
Minimum Order Quantity 50kg
Price $22.1/kg-$25.8/kg
Packaging Details Standard export package
Delivery Time 3 to 25 work days
Supply Ability 60 Tons per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Item 3.7165 Round Bar In Titanium Grade 5 Material Titanium Alloy Material Grade 5 6Al4V UNS R56400
Diameter 3mm To 450mm Diameter Tolerance H7, H8, H9
Length As Per Request Application CNC Machining, CAD/CAM Abutments, Turbine Blades, Structural Parts
Test Report Provide Factory MTC Or Third Party Test Report Quality Assurance Titanium Sponge Material, Standardized Production
Key Words 3.7165 Round Bar Advantage Large Stock, Short Lead Time
Highlight

3.7165 Titanium Round Bar

,

Grade 5 Titanium Round Bar

,

CNC Machining Titanium Round Bar
Leave a Message
Product Description

3.7165 Round Bar In Titanium Grade 5 CNC Machining Bar Material



3.7165 is the material number of titanium alloy Ti-6Al-4V (also known as Grade 5 titanium alloy) in the German Industrial Standard (DIN). This alloy is one of the most widely used titanium alloys and is favored in many fields due to its excellent comprehensive properties. As a workhorse material, Grade 5 titanium bar, especially Grade 5 titanium round bars are the star product we produced and exported to our clients.



Designation Ti6Al4V
W-Nr. 3.7165
Standard ASTM B348 ASTM F136 AMS4928
Category Alloy Titanium
Property Corrosion Resistance
Density 4.506 g/m³



Chemical Components

Ti-6al-4v is mainly composed of titanium (Ti), aluminum (Al) and vanadium (V), and its typical chemical composition is: titanium (Ti) residual, aluminum (Al) 5.5-6.75%, vanadium (V) 3.5-4.5%, and the limit of impurity elements such as iron (Fe), carbon (C), nitrogen (N), oxygen (O) and hydrogen (H).



Physical and Mechanical Properties

Ti-6Al-4V has high strength and good plasticity, with a density of 4.406 g/cm³ and a melting point of about 1650°C. At room temperature, the ultimate strength of the alloy is about 130 KSI (about 895 MPa, min.), the yield strength (0.2% offset) is about 120 KSI (about 828MPa, min.), and the elongation is about 10%.



Corrosion Resistance

3.7165 has good corrosion resistance to seawater, Marine atmosphere and a variety of corrosive media below 300°C. This makes it widely used in Marine engineering, chemical equipment and biomedical implants.



Application Fields

Ti-6Al-4V has a wide range of applications, including aerospace and aircraft structural parts, sports equipment, the medical industry (such as artificial joints and bone implants), the chemical industry, and more.

Ti6Al4V Titanium alloy is mainly used in aerospace to manufacture various beams, landing gear beams, blades, shells, pressure vessels and various types of fasteners in aircraft structures, which can reduce the weight of parts by about 30%.

Ti6Al4V Titanium alloys are widely used in the civil industry. For example, gas turbine blades in the electric power industry, ship thrusters in the shipbuilding industry, offshore oil drilling platforms in Marine engineering, various corrosion resistant pumps in the chemical industry, artificial implants in medicine, various sports equipment and so on.

Ti6Al4V Titanium alloy can be used in the manufacture of automobile frames, crank shafts, connecting rods, bolts, oil intake valves and suspension springs.



Supply Condition Annealed
Aircraft Turbines Engine Components Chemical Processing Industrials
Marine Applications Aerospace Fasteners High-Performance Automatic Parts
Aircraft Structural Components Medical Industry Sports Equipment



Machining and Welding

Ti Gr5/3.7165 has good thermoforming properties and is easy to weld. It is suitable to use wire made of the same grade titanium as the solder.



Ti6Al4V Titanium Round Bar Advantages

  • Excellent biocompatibility

  • Anti-corrosion. It is not corroded in seawater, wet chlorine, chlorite and hypochlorite solutions, nitric acid, metal chlorides, sulfides and organic acids

  • Can be aesthetically veneered with ceramic

  • Non-magnetic and non-toxic
  • Good milling properties due to low hardness

  • X-ray translucent

  • Low thermal conductivity

  • Light weight

  • Tensile strength above 1100Mpa
  • Yield strength above 1000Mpa
  • Testing: Tensile strength test, yield strength test, hardness test, nondestructive testing, chemical composition test, etc,.
  • Surface quality: High precision, good finish, no cracks, peeling.



Other Ti Material We Supply:

  • Grade 1-4 : Commercial Pure Ti
  • Grade 5: Ti-6AI-4V
  • Grade 6: Ti-5AI-2.5Sn
  • Grade 7: Ti-0.2Pb
  • Grade 9: Ti-3AI-2.5V
  • Grade 12: Ti-0.3Mo-0.8Ni
  • Grade 23: Ti-6AI-4V ELI
  • TC11: Ti-6.5Al-3.5Mo-1.5Zr-0.3Si



Titanium Round Bars

3.7165 Round Bar In Titanium Grade 5 CNC Machining Bar Material 0

We are titanium bar manufacturer, locates at Baoji City, China, which also called "Titanium Valley of China". We supply high quality titanium bars with good price and short lead time. Our main exporting areas include United states, Canada, Germany, UK, France, Turkey, South Korea, Saudi Arabia, Vietnam, etc,. Welcome to send your inquiry, thanks.
